Overview

• Freescale® i.MX6DL
• ARM Cortex™-A9
• 2x cores, 1 GHz

Powered by Freescale i.MX 6: i.MX 6 DualLite

The iMX6 is a small sized computer module that comes in dual core CPUs based on Freescale i.MX6DL. The Cortex A9 dual core CPU peaks at 1 GHz for commercial temperature variant.

Suitable for wide range of Industrial Applications

The module targets a wide range of applications, including: Digital Signage, Medical Devices, Navigation, Industrial Automation, HMIs, Avionics, Entertainment system, POS, Data Acquisition, Thin Clients, Robotics, Gaming and much more. It offers a wide range of interfaces from simple GPIOs, industry standard I2C, SPI, CAN, and UART buses through to high speed USB 2.0 interfaces and a 16/32bit external memory bus (parallel bus).

Specifications

CPU Name	Freescale® i.MX6DL
CPU Type	ARM Cortex™-A9
Multicore	Dual Core
CPU Clock	1.0 GHz
Floating Point Unit	VFPv3
NEON	Yes
L1 Instruction Cache	32KByte per core
L1 Data Cache	32KByte per core
L2 Cache	512KByte
RAM	1GB DDR3 (64 Bit)
Flash	4GB eMMC (8 Bit)
External Bus	32 Bit
USB	1x Host (High Speed) 1x OTG (High Speed)
I2C	3x
SPI	4x
UART	5x
IrDA	1x
PWM	4x
GPIO	Up to 154
Analog Input	4x (12 Bit)
Ethernet	10/100 Mbit
SDIO/SD/MMC	3x 8 Bit
CAN	2x
Display Controller	Single
Graphics Controller	Vivante GC880
Video Decoder	DivX 3/4/5/6, H.263, H.264, MJPEG, MPEG-2, MPEG4, VC1
S/PDIF In / Out	1x
2D Acceleration	Yes
3D Acceleration	Yes
HDMI	V1.4a 1080p (1920x1080)
RGB	1920x1200x24bpp
Resistive Touch	4-wire
Camera Parallel Interface	2x
Analog Audio Line in	1x (Stereo)
Analog Audio Mic in	1x (Mono)
Analog Audio Headphone out	1x (Stereo)
Windows Embedded Compact 7	Supported
Windows Embedded Compact 2013	Supported
Embedded Linux	Supported
Preinstalled OS	Samples: Linux; Volume: Windows Embedded Compact 2013
Size	67.6 x 36.7 x 6.2 mm
Temperature	0° to 70° C
Power Dissipation	0.6 - 2.3 W
Minimum Availability	2028
