Product Description

Control eight SPDT relay outputs via any 10/100BaseT Ethernet connection with the EO-800 I/O module. The.SPDT relays provide long-life switch closures well suited to low-current devices. Each SPDT relay has a discrete common and each pair of inputs share a common for easy field wiring via removable 5.5mm terminal blocks.

The EO-800 receives power via a removable spring-clamp terminal block. The lever-style clamping mechanism requires no tools, which simplifies field installation. The module is powered by your 9-30VDC source.

Ready for DIN rail mounting, the EO-800 includes a removable plastic clip that snaps onto 35mm DIN rail. The clip can also be attached to any flat surface such as a wall or under a counter. Standard operating temperature range of Ethernet modules is 0C to +70C. Status LEDS on the front show power and I/O activity. Additionally, LEDs on the RJ45 connector display Ethernet link and communication activity.

Specifications

Outputs	Channels 8
Contact Form	SPDT (Form C) (Direct access to dry contacts)
Contact Material	Ag (Au clad)
Resistive Load	10 A @ 30 VDC, 250 VAC, 110 VAC
Pulse Timer Duration	100ms to 86400 Seconds
Regulatory Compliance	Electromagnetic
General
Network	10/100Base-T Ethernet
Protocol	Modbus/TCP, TCP/IP, UDP, HTTP, DHCP
Power Input	10 - 30 VDC (24 VDC Standard)
Power Consumption	4.5 W @ 24 VDC
Connector	Plug-in 3P/12P Screw Terminal Blocks
Enclosure	PC
Mounting	DIN 35 Rail, Stack, Wall
Software
.NET Class Library (SDK)	Windows and Windows CE Class Library, VB and VC# Sample Code for I/O Reading or Configuration and Communication
Compliance:	IEC CISPR 22, CISPR 24 FCC 47CFR15 (-I and -5 Models class B, POE Model Class A) EU EN55024, EN55022
Product Safety	IEC 60950-1 / EN 60950-1 CE FCC
